Ensure the supplied power cable is fully compatible with your
power outlet. In some cases an adaptor (not supplied) may be
required to ensure a fully earthed connection.
1
Power supply inlet IEC socket. Image shows PF7+. PF7 rear panel looks
slightly different. Power supply inlet is located in the same place.
Figure 12 - Power supply socket
PF7/PF7+ Peristaltic Filler with QC14 Pumphead User Manual 30
