Flexim PIOX S72 Series User Manual

7 Mounting
PIOX S72* 7.2 Transducers
57
UMPIOX_S72xV1-9EN, 2022-05-15
7.2.2.6 Mounting with PermaLok
Scope of delivery
2 × PermaLok
1 × transducer pair
4 × quick release clasp with
tension strap
Fig. 7.58: PermaLok components
1–cover
2–screw
3 – nut
4 – slider
5 – screw of the slider
6–rail
7 – cable bushing
8 – support
9 – tension strap clamp (optional)
10 – bolt (optional)
1
2
3
6
9
4
5
10
7
8
