Configuration and Operation
44
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
·
Check the Continuous image upload box if you wish to upload an image by e-mail for a
defined period of time or while the trigger is active. Select one of the following options:
·
To specify the length of time for the upload, select Upload for and enter the number of
seconds in the text box.
·
To upload while the trigger is active, select Upload while the trigger is active.
In the Image Frequency text box, from the drop-down list select the number of frames per
seconds from 1-15 for the upload.
Note:
Make sure that SMTP configuration has been completed. See Mail for details.
·
Send HTTP notification – Select this checkbox to send a notification by HTTP. Select the
destination HTTP address from the drop-down menu and specify the parameters for event
notifications by the IO event triggered. When an alarm is triggered, the notification will be sent to
one of two specified HTTP servers. See figure below.
Send HTTP Notification Settings
·
Record video clip – Select this box in order to save the alarm-triggered recording to your
microSDXC card or to the NAS. Enter the number of seconds for the pre-trigger buffer. Select the
first radial button if you wish to upload for a specified length of time and enter the number of
seconds. Alternatively, select the second radial button to upload while the trigger is active.
Record Video Clip Settings
Note:
In order to use this function, make sure that local recording with a microSDXC card is activated
and that the NAS is properly configured. See Recording for further details.
·
PTZ Function – Select this checkbox to set a Preset, Sequence, Auto Pan, or Pattern; Function
line; or Dwell time. These functions can be configured in more detail from the Settings > PTZ tab.
PTZ Function Settings
Click SAVE after configuring the settings.
