5322A
Operators Manual
18
Table 5. Front-Panel Features (cont.)
Item Description
H
Output Adjustment Controls
If any of these keys are pushed or the rotary knob is turned,
a digit on the OUTPUT area of the display is highlighted.
The output increments or decrements as the rotary knob is
turned. If a digit rolls past 0 or 9, the digit to its left or right is
carried.
When making a menu selection, pushing in the rotary knob
is equivalent to pushing the SELECT softkey. When editing
a number, pushing in the rotary knob switches between
moving the cursor between characters and changing the
selected character’s value. Arrow icons above and below
the selected digit indicate which of the two modes are
active.
and adjust the magnitude of changes by moving the
highlight between the digits.
and increment and
decrement respectively the value of the highlighted digit.
I Impedance and RCD Keys
Selects the impedance and RCD functions. These functions
are:
Loop/Line Impedance
Ground Bond Resistance
RCD Time & Trip current
J
Selects the meter function.
K Softkeys
The functions of the five unlabeled softkeys are identified by
labels in the display panel directly above each key. The
functions change during operation so that many different
functions are accessible through these keys. A group of
softkey labels is called a menu. A group of interconnected
menus is called a menu tree.
