Multifunction Electrical Tester Calibrator
Front-Panel Operation
19
Table 5. Front-Panel Features (cont.)
Item Description
L Meter Terminals
Provides connection points for meter measurements. The V terminal
is for ac and dc voltages up to 1100 V dc/ac. The HV terminal, also
referred to as the HV 5 kV Probe, measures up to 5000 V ac rms or
dc. The A terminal is for ac and dc currents. The COM terminal is the
return for all meter measurements.
M Impedance and RCD
Terminals
Provides connection points for the Loop and Line impedance
testing as well as RCD testing and Ground Bond Resistance
testing.
