5322A

Operators Manual

5. Simulate leakage current using the 5322A LOAD instrument connected

between the Hi signal terminal of the HIPOT tester and the Meter A input

terminal. See Figures 23, 24, and 25.


Figure 23. Multimeter Display with Hipot Leakage Current Measurement for Voltages <1100 V

HIPOT Tester

Fluke 5322A-LOAD

Fluke 5322A

iep061.eps

Figure 24. HIPOT LC Function Connections for <1100 V
