Vertical flanged machines – vertiSWEEP
Measure using vertiSWEEP
l Center the laser beam.
Note
vertiSWEEP is the default measurement mode for vertically mounted machines.
The alternative Static clock measurement mode may be accessed by tapping (1)
in screen below.
l Position the shafts such that sensor and laser are both at the '0' reference mark pos-
ition.
l
Use or and select the direction in which the shafts will be rotated. Once
the direction to rotate the shafts is selected, measurement is activated and the letter 'M'
(1) appears and also (2) becomes active.
l
Tap either 'M' or then rotate the shafts through an angle greater than 360°.
l
After rotating the shafts through the required angle, tap (1) to display coupling
results. Tap (2)to display shimming corrections.
110 Version:2.3
