Cardan shaft alignment – Using cardan offset bracket
Cardan offset brackets
Two types of cardan offset brackets are available.
l The large type allows precise measurement of machines joined by cardan shafts over
distances of up to 10 m (33 ft) and shaft offsets of up to 1000 mm (39 3/8 in.).
l The smaller type also referred to as Lite, allows precise measurement of machines
joined by cardan shafts over distances of up to 3 m (10 ft) and shaft offsets of up to 400
mm (15 3/4 in.).
l "Mounting cardan offset bracket lite (sensALIGN 5 EX laser)" on page141
Note
Both sets of cardan offset brackets (large and lite) may be used with sensALIGN 5
sensor/laser combination.
