Components
The main measuring components for shaft alignment are the intrinsically safe ruggedized tab-
let, the intrinsically safe sensor, the intrinsically safe laser and the intrinsically safe RF mod-
ule.
Ruggedized tablet
Note
For details on usage of the ruggedized tablet please refer to the included ecom tablet
manual.
The only application running on this intrinsically safe ruggedized tablet is Shaft Align-
ment. Additional apps cannot be installed in this dedicated device.
In this version of the tablet device, the hard keys (3 and 4) have been disabled. The
hard key (2) may be used to capture screenshots.
Starting the Shaft Alignment application
Switch the ruggedized tablet on by pressing and holding down the power key (1). Once
switched on, the application home screen opens.
16 Version:2.3
On-board help
