l (1) Washer
l (2) Spacer
l (3) T-nut bolt
l (1) Reference surface
This coupling example has a raised face flange. The provide spacers are used to create a
three-point plane to ensure that the faceplate and the coupling surface are joined together.
Note
Do not bolt down the faceplate as the laser is still to be adjusted.
ROTALIGNtouch EX 139
On-board help
