4. Use the chain-type bracket or appropriate magnetic brackets to mount the sensor on the
shaft of the machine to be moved (such as the motor or gearbox). The sensor is aligned to the
laser by pushing or sliding the bracket supporting the sensor.
Note
DO NOT touch the laser or its laser position thumbwheels.
