Note
Other measurement modes for cardan shafts when using sensALIGN 5 sensor and laser
can be either multipoint or the cardan mode measurement.
5. Tap either the pulsating M (2) or (3) to take initial measurement point.
6. Rotate the sensor and the laser to the next measurement position.
7. Use or to position the displayed laser at the desired measurement position,
then tap the pulsating M to take measurement at the selected clock position.
