l The wizard arrows decrease in magnitude and occurrence as the laser beam status
improves, disappearing completely once the laser beam is centered.
l Measurement may commence once the laser beam is centered.
It may however be necessary to preadjust the laser beam without using the wizard. In that
case, proceed as follows:
l "Laser beam adjustment (sensALIGN 5 EX)" on page36
ROTALIGNtouch EX 39
