Fortinet FortiGate FortiGate-3000 Administration Guide

System config SNMP
FortiGate-3000 Administration Guide 01-28006-0010-20041105 107
To configure SNMP access to an interface in Transparent mode
Before a remote SNMP manager can connect to the FortiGate agent, you must
configure one or more FortiGate interfaces to accept SNMP connections. See “To
configure the management interface” on page 66.
1 Go to System > Network > Management.
2 Choose an interface that the SNMP manager connects to and select SNMP.
3 Select Apply.
To enable SNMP and configure basic SNMP settings
1 Go to System > Config > SNMP v1/v2c.
2 Select the Enable check box to enable the FortiGate SNMP Agent.
3 Configure the following SNMP settings: Description, Location, and Contact.
4 Select Apply.
5 Add one or more SNMP communities.
To add an SNMP community
1 Go to System > Config > SNMP v1/v2c.
2 Select Create New.
3 Enter a Community Name to identify the SNMP community.
4 Configure Hosts, Queries, Traps, and SNMP Events.
5 Select OK.
FortiGate MIBs
The FortiGate SNMP agent supports FortiGate proprietary MIBs as well as standard
RFC 1213 and RFC 2665 MIBs. RFC support includes support for the parts of RFC
2665 (Ethernet-like MIB) and the parts of RFC 1213 (MIB II) that apply to FortiGate
unit configuration.
The FortiGate MIBs are listed in Table 6. You can obtain these MIB files from Fortinet
technical support. To be able to communicate with the SNMP agent, you must
compile all of these MIBs into your SNMP manager.
Your SNMP manager might already include standard and private MIBs in a compiled
database that is ready to use. You must add the Fortinet proprietary MIBs to this
database. If the standard MIBs used by the Fortinet SNMP agent are already
compiled into your SNMP manager you do not have to compile them again.
Table 6: FortiGate MIBs
MIB file name or RFC Description
fortinet.2.80.mib The Fortinet MIB is a proprietary MIB that includes detailed FortiGate
system configuration information. Add this MIB to your SNMP
manager to monitor all FortiGate configuration settings. For more
information about FortiGate MIB fields, see “FortiGate MIBs” on
page 107.
