SNMP System config
Fortinet MIB fields
The Fortinet MIB contains fields reporting current FortiGate unit status information.
The tables below list the names of the MIB fields and describe the status information
available for each one. You can view more details about the information available
from all Fortinet MIB fields by compiling the fortinet.2.80.mib file into your SNMP
manager and browsing the Fortinet MIB fields.
Table 12: FortiGate logging traps
Trap message Description
Log full
(SysLogFull)
On a FortiGate unit with a hard drive, hard drive usage exceeds 90%. On a
FortiGate unit without a hard drive, log to memory usage has exceeds 90%.
Table 13: FortiGate HA traps
Trap message Description
Primary unit
switch
(HaSwitch)
The different unit in the HA cluster became the primary unit.
Table 14: System MIB fields
MIB field Description
model FortiGate model number, for example, 400 for the FortiGate-400.
serial FortiGate unit serial number.
version The firmware version currently running on the FortiGate unit.
versionAv The antivirus definition version installed on the FortiGate unit.
versionNids The attack definition version installed on the FortiGate unit.
haMode The current FortiGate High-Availability (HA) mode (standalone, A-A, A-P)
opMode The FortiGate unit operation mode (NAT or Transparent).
cpuUsage The current CPU usage (as a percent).
memUsage The current memory utilization (in MB).
sesCount The current IP session count.
