108 01-28006-0010-20041105 Fortinet Inc.
SNMP System config
FortiGate traps
The FortiGate agent can send traps to SNMP managers that you have added to
SNMP communities. For SNMP managers to receive traps, you must load and
compile the Fortinet trap MIB (file name fortinet.trap.2.80.mib) onto the SNMP
manager.
All traps include the trap message as well as the FortiGate unit serial number.
fortinet.trap.2.80.mib The Fortinet trap MIB is a proprietary MIB that is required for your
SNMP manager to receive traps from the FortiGate SNMP agent. For
more information about FortiGate traps, see “FortiGate traps” on
page 108.
RFC-1213 (MIB II) The FortiGate SNMP agent supports MIB II groups with the following
exceptions.
No support for the EGP group from MIB II (RFC 1213, section 3.11
and 6.10).
Protocol statistics returned for MIB II groups (IP/ICMP/TCP/UDP/etc.)
do not accurately capture all FortiGate traffic activity. More accurate
information can be obtained from the information reported by the
Fortinet MIB.
RFC-2665 (Ethernet-
like MIB)
The FortiGate SNMP agent supports Ethernet-like MIB information
with the following exception.
No support for the dot3Tests and dot3Errors groups.
Table 6: FortiGate MIBs
MIB file name or RFC Description
Table 7: Generic FortiGate traps
Trap message Description
ColdStart
WarmStart
LinkUp
LinkDown
Standard traps as described in RFC 1215.
