Fortinet FortiGate FortiGate-3000 Administration Guide

218 01-28006-0010-20041105 Fortinet Inc.
Schedule Firewall
Service group has the following options.
Configuring service groups
To organize services into a service group
1 Go to Firewall > Service > Group.
2 Select Create New.
3 Enter a group name to identify the service group.
4 Select a service from the Available Services list and select the right arrow to move the
service into the group.
5 Select OK.
To delete a service group
If a service group is included in a policy, it cannot be deleted unless it is first removed
from the policy.
1 Go to Firewall > Service > Group.
2 Select the Delete icon beside the service group you want to delete.
3 Select OK.
To edit a service group
1 Go to Firewall > Service > Group.
2 Select the Edit icon beside the service group you want to modify.
3 Make any required changes.
4 Select OK.
Schedule
Use schedules to control when policies are active or inactive. You can create one-time
schedules and recurring schedules.
You can use one-time schedules to create policies that are effective once for the
period of time specified in the schedule. Recurring schedules repeat weekly. You can
use recurring schedules to create policies that are effective only at specified times of
the day or on specified days of the week.
Group Name Enter a name to identify the address group.
Available
Services
The list of configured and predefined services. Use the arrows to move
services between the lists.
Members The list of services in the group. Use the arrows to move services between
the lists.
Note: To change the service group name you must delete the service group and add it with a
new name.
