Fuji Electric FRENIC MEGA G2 Series - Page 199

5.2 Function Code Tables
5-15
FUNCTION CODES
Chap 5
*3: The motor rated current is automatically set. Refer to Table 5.2-2 Motor constants (function code P03).
Function
code
Name
Control method and Data setting range
Change when
running
Data copying
Factory
default
Related page
E52
Keypad menu selection
0: Function code data setting mode (Menu 0, Menu 1, and Menu 7)
1: Function code data check mode (Menu 2 and Menu 7)
2: Full-menu mode
Y
Y
2
5-183
E54
Frequency detection 3
(Level)
0.0 to 599.0 Hz
Y
Y
60.0
5-183
E55
Current detection 3 (Level)
*Same as E34
Y
Y1
Y2
*3
5-183
E56
(Timer)
*Same as E35
Y
Y
10.00
E57
Integral power pulse output
unit
0: Pulse output every 0.1 kWh
1: Pulse output every 1 kWh
2: Pulse output every 10 kWh
3: Pulse output every 100 kWh
4: Pulse output every 1000 kWh
Y
Y
1
5-184
E61
Terminal [12] extended
function
0: No extension function assignment
1: Auxiliary frequency setting 1
2: Auxiliary frequency setting 2
3: PID command 1
5: PID feedback value
6: Ratio setting
7: Analog torque limit value A
8: Analog torque limit value B
9: Torque bias
10: Torque command
11: Torque current command
12: Acceleration/deceleration time ratio setting
13: Upper limit frequency
14: Lower limit frequency
15: Auxiliary frequency setting 3
16: Auxiliary frequency setting 4
17: Speed limit for forward rotation (FWD)
18: Speed limit for reverse rotation (REV)
20: Analog signal input monitor
N
Y
0
5-184
E62
Terminal [C1] (C1 function)
(Extension function
selection)
N
Y
0
E63
Terminal [V2]
N
Y
0
E64
Saving of digital reference
frequency
0: Auto saving (main power is turned off)
1: Save by turning key ON
Y
Y
0
5-186
E65
Reference loss detection
(Continuous running
frequency)
0: Stop deceleration
20 to 120%, 999: Cancel
Y
Y
999
5-187
E66
Terminal [C1] (V3 function)
(Extension function
selection)
*Same as E61
N
Y
0
E70
M/Shift key
(Function selection)
See E70 in “Table 5.2.2 Control input terminal setting list table”.
N
Y
100
5-188
E71
M-LED indicator
(Function selection)
See E71 in “Table 5.2.3 Control output terminal setting list table”.
N
Y
100
E76
DC link bus low-voltage
detection level
200 to 400 V (200V series)
400 to 800 V (400V series)
Y
Y2
235
470
5-188
E78
Torque detection 1 (Level)
0 to 300%
Y
Y
100
5-189
E79
(Timer)
0.01 to 600.00 s
Y
Y
10.00
E80
Torque detection 2/
low torque detection (Level)
Same as E78
Y
Y
20
E81
(Timer)
*Same as E79
Y
Y
20.00
E98
Terminal [FWD] function
See E98, E99 in “Table 5.2.2 Control input terminal setting list table”.
N
Y
98
5-189
E99
Terminal [REV] function
N
Y
99
