5.2 Function Code Tables
5-14
Function
code
Name
Control method and Data setting range
Change when
running
Data copying
Factory
default
Related page
E29
Frequency arrival delay timer (FAR2)
0.01 to 10.00 s
Y
Y
0.10
5-172
E30
Frequency arrival detection width
(Detection width)
0.0 to 10.0 Hz
Y
Y
2.5
E31
Frequency detection 1
(operation level)
0.0 to 599.0 Hz
Y
Y
60.0
5-174
E32
(Hysteresis width)
0.0 to 599.0 Hz
Y
Y
1.0
E34
Overload early warning/Current
detection
(Level)
0.00 (Disable), 1 to 200% of inverter rated current
(Inverter rated current dependent on F80)
Y
Y1
Y2
*3
5-175
E35
(Timer)
0.01 to 600.00 s
Y
Y
10.00
E36
Frequency detection 2 (Level)
0.0 to 599.0 (Hz)
Y
Y
60.0
5-176
E37
Current detection 2/Low current
detection (Level)
*Same as E34
Y
Y1
Y2
*3
5-176
E38
(Timer)
*Same as E35
Y
Y
10.00
E39
Constant rate of feeding coefficient 1/
Speed display auxiliary coefficient 1
0.000 to 9.999
Y
Y
1.000
5-176
E42
LED display filter
0.0 to 5.0 s
Y
Y
0.5
5-177
E43
LED monitor (display selection)
0: Speed monitor (Selectable with E48)
3: Output current
4: Output voltage
8: Calculated motor output torque
9: Power consumption
10: PID process command
12: PID feedback value
13: Timer value
14: PID output
15: Load factor
16: Motor output
17: Analog signal input monitor
21: Current position
22: Positioning deviation
23: Torque current (%)
24: Magnetic flux command(%)
25: Input watt-hour
26: Winding diameter
27: Position control start position
28: Stop target position
29: PID deviation
30: Torque bias
31: Estimated inertia acceleration/deceleration time conversion
value (coming soon)
32: Customizable logic output
Y
Y
0
5-177
E44
(Display when stopped)
0: Specified value
1: Output value
Y
Y
0
5-179
E48
LED monitor details
(Speed monitor selection)
0: Output frequency 1 (before slip compensation)
1: Output frequency 2 (after slip compensation)
2: Reference frequency
3: Motor rotation speed
4: Load rotation speed
5: Feed speed
6: Transport time for specified length
7: Speed (%)
8: Line speed set value
9: Line speed output value
Y
Y
0
5-179
E49
Torque Command Monitor
(Polarity selection)
0: Torque polarity
1: Plus for driving, Minus for braking
Y
Y
1
5-180
E50
Display coefficient for speed monitor
0.01 to 600.00
Y
Y
30.00
5-182
E51
Display coefficient for “Input watt-hour
data”
0.000 (Cancel/Reset), 0.001 to 9999
Y
Y
0.010
5-182
*3: The motor rated current is automatically set. Refer to Table 5.2-2 Motor constants (function code P03).
