3.3 Running Mode
3-7
Chapter 3
KEYPAD FUNCTIONS
Analog input
monitor (*8)
8"00
HzAkW -
An analog input to the inverter in
a format suitable for a desired
scale.
Refer to function codes E40 and
E41 for details.
17
Torque current
(*9)
48
HzAkW
%
Torque current command value or
calculated torque command
23
Magnetic flux
command
50
HzAkW %
Magnetic flux command value
(Available only under vector
control)
24
Input watt-hour
10*0
HzAkW kWh
100
(kWh ） hour- wattInput
25
On, Off
(*1) A value exceeding 9999 cannot be displayed as is on the 4-digit LED monitor screen, so the LED monitor
displays one-tenth of the actual value with the x10 LED lit.
(*2) When the LED monitor displays an output voltage, the 7-segment letter
u
in the lowest digit stands for the
unit of the voltage "V."
(*3) These PID related items appear only when the inverter drives the motor under the PID control specified by
function code (J01 = 1, 2 or 3).
(*4) When the LED monitor displays a PID command or its output amount, the dot (decimal point) attached to
the lowest digit of the 7-segment letter blinks.
(*5) When the LED monitor displays a PID feedback amount, the dot (decimal point) attached to the lowest
digit of the 7-segment letter lights.
(*6) When the LED monitor displays a load factor, the 7-segment letter
;
in the lowest digit stands for "%."
(*7) When the LED monitor displays the motor output, the unit LED indicator "kW" blinks.
(*8) The analog input monitor can appear only when the analog input monitor function is assigned to any of the
analog input terminals by any of function codes E61 to E63.
(*9)
0
appears under the V/f control.
Excepting the speed monitor (E43 = 0), the monitor display of various running status on the
keypad can be filtered. If the display varies unstably so as to be hard to read due to load
fluctuation or other causes, increase this filter value. ( Function code E42)
