Fuji Electric Frenic Mega Series - Series)

A-37
App. G Replacement Information
App.
vs. FRENIC5000G9S
FRENIC5000G9S FRENIC-MEGA
Default
setting
Default
setting
Code Name Data setting range
22 kW or
below/30 kW
or above
Code Name Data setting range
22 kW or
below/30 kW
or above
Basic function
00 Frequency
Command
0: Setting by keypad operation ( and
keys)
F01 Frequency Command 1
0: Enable / keys on the keypad
0
1: Voltage input
(0 to 10 VDC, Terminals [12] + [V1]), when
[V1] is not used.
F01 Frequency Command 1 1: Voltage input to terminal [12] (0 to ±10 VDC) 0
F01 Frequency Command 1 1: Voltage input to terminal [12] (0 to ±10 VDC) 0
E63 Terminal [V2] Extended Function 1: Auxiliary frequency command 1 0
1: Voltage input
(0 to 10 VDC, Terminals [12] + [V1]), when
[V1] is used.
C45 Analog Input Adjustment Polarity 0: Bipolar 1
2: Sum of voltage and current inputs
(Terminals [12] + [V1] + [C1]), when [V1] is not
used.
F01 Frequency Command 1 3: Sum of voltage input to terminals [12]
and current input to [C1]
0
2: Sum of voltage and current inputs
(Terminals [12] + [V1] + [C1]), when [V1] is
used.
F01 Frequency Command 1 3: Sum of voltage input to terminals [12]
and current input to [C1]
0
E63 Terminal [V2] Extended Function 1: Auxiliary frequency command 1 0
0
C45 Analog Input Adjustment Polarity 0: Bipolar 0
01 Operation Method
0: / keys on keypad
F02 Operation Method 0: Keypad operation
(Rotational direction specified by terminal command)
2: Keypad operation (Forward rotation)
3: Keypad operation (Reverse rotation)
1: Terminal command ([FWD] or [REV])
0
1: External signals (Digital input terminal
commands)
2
02 Maximum
Frequency
G9S: 50 to 400 Hz, P9S: 50 to 120 Hz 60 F03 Maximum Frequency 1 25.0 to 500.0 Hz 60.0
03 Base Frequency 1 G9S: 50 to 400 Hz, P9S: 50 to 120 Hz 50 F04 Base Frequency 1 25.0 to 500.0 Hz 50.0
04 Rated Voltage 1 0: AVR control OFF
(Output a voltage in proportion to input
voltage)
F05 Rated Voltage at Base Frequency 1 0: AVR disabled
Output a voltage in proportion to input
voltage
80 to 240 V (200 V class series)
160 to 500 V (400 V class series)
200
(200 V class
series)
400
(400 V class
series)
(Maximum Output Voltage 1) 80 to 240 V: (200 V class)
320 to 480 V: (400 V class)
200
(200 V class
series)
400
(400 V class
series)
F06 Maximum Output
Voltage 1
80 to 240 V (200 V class series)
160 to 500 V (400 V class series)
200
(200 V class
series)
400
(400 V class
series)
05 Acceleration Time 1 0.01 to 3600 s 6.0/20.0 F07 Acceleration Time 1 0.00 to 6000 s 6.00/20.00
