9.2 Overview of FRENIC Loader
9-8
9.2 Overview of FRENIC Loader
FRENIC Loader is a software tool that supports the operation of the inverter via an RS-485
communications link.
It allows you to remotely run or stop the inverter, edit, set, or manage the function codes, monitor key
parameters and values during operation, as well as monitor the running status (including alarm history) of
the inverters on the RS-485 communications network.
With special order-made inverters, FRENIC Loader may not be able to display some function
codes normally.

For details, refer to the FRENIC Loader Instruction Manual.
9.2.1 Specifications
Table 9.2-1
Item Specifications Remarks
Name of software FRENIC Loader
Supported inverter FRENIC-MEGA/Multi/Eco/Mini (Note 1)
No. of supported
inverters
When connected to USB port: 1
When connected to RS-485
communications ports: Up to 31
Recommended cable 10BASE-T cable with RJ-45 connectors
compliant with EIA568
For the RS-485 interface
CPU Intel Pentium III 600 MHz or later (Note 2)
OS Microsoft Windows 2000 (Japanese Ver.)
Microsoft Windows XP (Japanese Ver.)
Microsoft Windows Vista (32 bits, 64 bits)
Microsoft Windows 7 (32 bits, 64 bits)
Memory 512 MB or more RAM 1 GB or more is
recommended.
Hard disk 20 MB or more free space
Serial port RS-232C (conversion to RS-485
communication required to connect
inverters) or USB
Operating environment
Monitor resolution 800 x 600 or higher XGA (1024 x 768), 32-bit
color or higher is
recommended
COM port COM1 to COM255 PC COM ports assigned to
Loader
Transmission rate When connected to USB port:
Between loader and keypad
 = fixed at 12 (Mbps)
Between keypad and inverter
 = fixed at 19200 (bps)
When connected to RS-485
communications ports:
38400, 19200, 9600, 4800, 2400 (bps)
19200 bps or more is
recommended.
(Note 3)
Character length 8 bits Prefixed
Stop bit length 1 bit Prefixed
Parity Even Prefixed
No. of retries None or 1 to 10 No. of retry times before
detecting communications
error
Transmission requirements
Timeout setting (100 ms, 300 ms, 500 ms), (1.0 to 1.5 to
1.9 s), (2.0 to 9.0 s) or (10.0 to 60.0 s)
This setting should be longer
than the response interval
time set by function code y09
of the inverter.
(Note 1) FRENIC Loader cannot be used with inverters that do not support SX protocol (protocol for
handling Loader commands).
