5.3 Code Index by Purpose
5-57
Chapter 5 Function Code
To:
Function
code
Name
Refer to
page:
Overload early
warning
Output an overload early warning before the
inverter trips with the electronic thermal
overload protection.
F10
F12
E34
E20 to E24
Electronic Thermal Overload
Protection for Motor 1
(Select motor characteristics)
(Thermal time constant)
Overload Early Warning/Current
Detection (Timer)
Terminal [Y1] to [Y5A/C]
Functions (OL)
5-80
5-153
5-141
Protect the motor from overheating with the
PTC or NTC thermistor embedded in the motor.
Motor overheat
Use the Fuji VG motor (exclusively designed for
vector control) having a built-in NTC thermistor.
H26
H27
SW5
Thermistor (for motor)
(Mode selection)
(Operation level)
< Switching the terminal [V2]
function >
5-189
2-34
Detection with
thermistor
Detect the current voltage with the PTC
thermistor embedded in the motor and issue an
alarm.
H26
H27
SW5
E20 to E24
Thermistor (for motor)
(Mode selection)
(Operation level)
< Switching the terminal [V2]
function >
Terminal [Y1] to [Y5A/C]
Functions (THM)
5-189
2-34
5-141
Dew
condensation
prevention
Prevent the motor being stopped from dew
condensation in cold climates by feeding DC
power, even during the inverter is stopped.
J21
F21
F22
E01 to E09
Dew Condensation Prevention
(Duty)
DC Braking 1
(Braking level)
(Braking time)
Terminal [X1] to [X9] Functions
(DWP)
5-227
5-94
5-122
[3] Using other protective and safety functions
Table 5.3-26
To:
Function
code
Name
Refer to
page:
Trip the inverter immediately if a momentary
power failure occurs.
Shut down the inverter output immediately to
allow the motor to coast to a stop without trip if
a momentary power failure occurs. Trip the
inverter when the power is restored.
Trip after
momentary power
failure (No
restart)
Decelerate the motor to a stop immediately if a
momentary power failure occurs. Trip the
inverter after the frequency drops down to zero.
F14
H15
H92
H93
E20 to E24
E01 to E09
Restart Mode after Momentary
Power Failure (Mode selection)
(Continuous running level)
Continuity of Running (P)
Continuity of Running (I)
Terminal [Y1] to [Y5A/C]
Functions (LU, IPF)
Terminal [X1] to [X9] Functions
(IL)
5-83
5-141
5-122
External alarm
Shut down the inverter output immediately in
the event of an abnormal situation in peripheral
equipment.
E01 to E09
Terminal [X1] to [X9] Functions
(THR)
5-122
Protective/maint
enance functions
Enable or disable the following functions.
- Automatic lowering of carrier frequency
- Input/output phase loss protection
- Judgment on the life of DC link bus capacitor
- DC fan lock detection
- Braking transistor failure detection
H98
Protection/Maintenance Function
(Mode selection)
5-208
Braking resistor
Use an external braking resistor and protect it
with the electronic thermal overload protection
function.
F50
F51
F52
Electronic Thermal Overload
Protection for Braking Resistor
(Discharging capability)
(Allowable average loss)
(Resistance)
5-119
Braking
transistor
Detect a breakdown of the braking resistor to
protect the inverter.
E20 to E24
Terminal [Y1] to [Y5A/C]
Functions (DBAL)
5-141
To Next Page
