11.4 Option
11-67
Chapter 11 SELECTING PERIPHERAL EQUIPMENT
[2] Multi-function keypad (TP-G1-J1, TP-G1-C1)
Replacing the standard keypad with the multi-function keypad enables setting and checking of function
code data, and monitoring of the inverter running status, on the LCD monitor.
Specifications
Table 11.4-32
Item Specifications
TP-G1-J1 Japanese, English, German, French, Spanish, and Italian
Language
TP-G1-C1 Chinese, English, Japanese, and Korean
Data copying function Capable of storing and copying function code data of up to three inverters
Applicable inverters FRENIC-Multi series, FRENIC-Eco series, and FRENIC-MEGA series
External view
Figure 11.4-27
