App. G Replacement Information
A-25
App.
App. G Replacement Information
When replacing Fuji conventional inverter series (FRENIC5000G9S/P9S, FRENIC5000G11S/P11S) with
the FRENIC-MEGA series, refer to the replacement information given in this section.
G.1 External dimensions comparison tables
Below is a guide that helps in using the comparison tables on the following pages.
• Mounting area
/MEGA(%)
Allows comparing the volume of the FRENIC-MEGA series with that of the conventional
inverter series in percentage, assuming the volume of the FRENIC-MEGA series to be
100%.
If this value is greater than 100%, it means that the volume of the FRENIC-MEGA is
smaller than that of other series.
• Volume
/MEGA(%)
Allows comparing the volume of the FRENIC-MEGA series with that of the conventional
inverter series in percentage, assuming the volume of the FRENIC-MEGA series to be
100%.
If this value is greater than 100%, it means that the volume of the FRENIC-MEGA is
smaller than that of other series.
• In the FRENIC-MEGA columns, dimensions in shaded boxes ( ) denote that they are smaller
than those of FRENIC5000G9S/P9S and FRENIC5000G11S/P11S series.
• In the FRENIC-MEGA columns, underlined and bolded
dimensions denote that they are larger than
those of FRENIC5000G11S and FRENIC5000P11S series.
Figure G-1
