5.3 Code Index by Purpose
5-51
Chapter 5 Function Code
To
Function
code
Name
Refer to
page:
C31
C36
C41
Analog Input Adjustment for:
[12] (Offset)
[C1] (Offset)
[V2] (Offset)
5-173
PID feedback Set up analog input feedback for PID control.
C33
C38
C43
Analog Input Adjustment for:
[12] (Filter)
[C1] (Filter)
[V2] (Filter)
5-173
PID optimization Optimize the PID processor.
J03
J04
J05
J06
J56
PID Control
P (Gain)
I (Integral time)
D (Differential time)
(Feedback filter)
(Speed command filter for PID)
5-219
5-228
Anti reset windup
Suppress overshoot in control with the PID
processor.
J10
PID Control
(Anti reset windup)
5-225
Output an alarm signal associated with PID
control (e.g., deviation alarm and
absolute-value alarm).
J11
J12
J13
E20 to E24
PID Control
(Select alarm output)
(Upper level alarm (AH))
(Lower level alarm (AL))
Terminal [Y1] to [Y5A/C]
Functions (PID-ALM)
5-225
5-141
Alarm output
PID Feedback Wire Break Detection
H91
E20 to E24
PID Feedback Wire Break
Detection
Terminal [Y] to [Y5A/C] Functions
(C1OFF)
5-207
5-141
Slow flowrate
stop feature
Use the slow flowrate stop feature, enabling
energy saving operation.
J15
J16
J17
E20 to E24
J08
J09
PID Control
(Stop frequency for slow flowrate)
(Slow flowrate level stop latency)
(Starting frequency)
Terminal [Y1] to [Y5A/C]
Functions (PID-STP)
PID Control (Pressurization
starting frequency)
PID Control (Pressurizing time)
5-223
5-141
Output limiter
Limit the PID output with the upper and lower
limiters.
J18
J19
PID Control
(Upper limit of PID process
output)
(Lower limit of PID process
output)
5-227
PID control
Hold/reset the PID processor or cancel PID
control from external equipment.
E01 to E09
Terminal [X1] to [X9] Functions
(PID-HLD, Hz/PID, PID-RST)
5-122
"Under PID
control" signal
output
Output the "Under PID control" signal from the
specified output terminal.
E20 to E24
Terminal [Y1] to [Y5A/C]
Functions (PID-CTL)
5-141
Display of
process value
Convert a control amount into a physical
quantity of the process and display it on the
keypad.
E40
E41
PID Display Coefficient A
PID Display Coefficient B
5-155
