5.4 Details of Function Codes
5-197
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C codes
P codes
H42 to H61
A codes
b codes
r codes
J codes
d codes
U codes
y codes
H45
Mock Alarm Related Function Code: H97 Clear Alarm Data
During the setup, a mock alarm can be generated in order to check the external sequence. Setting the H45
data to "1" displays mock alarm
err
. It also issues a bulk alarm ALM (if ALM is assigned to a
general-purpose digital output terminal E20 to E24 and E27).
To change the H45 data, it is necessary to press the "
key + key" (simultaneous keying). After that, the
H45 data automatically reverts to "0," allowing you to reset the alarm.
Just as data (alarm history and relevant information) of those alarms that could occur in running the inverter,
the inverter saves mock alarm data, enabling you to confirm the mock alarm status.
After completion of the setup, when deleting the mock alarm data, use H97 as when deleting alarm data
occurred during operations. (Changing the H97 data requires simultaneous keying of "
key + key.")
H97 data automatically returns to "0" after clearing the alarm data.
A mock alarm can be issued also by simultaneous keying of "
key + key" on the keypad
for 5 seconds or more.
H46
Starting Characteristics (Auto Search Wait Time 2) (See H09)
For details of the starting characteristics (auto search wait time 2), see the section of the function code H09.
H47, H48
Main Circuit Capacitor Initial Value, Cumulative Run Time of Capacitors on Printed
Circuit Boards (See H42)
For details of initial capacitance of main circuit capacitor and cumulative run time of capacitor on the printed
board, see the section of the function code H42.
H49
Starting Characteristics (Auto Search Wait Time 1) (See H09)
For details of starting characteristics (auto search wait time 1), see the section of the function code H09.
H50, H51
H52, H53
Non-linear V/f1 (Frequency, Voltage) (See F04)
Non-linear V/f2 (Frequency, Voltage)
For details of non-linear V/f pattern setting, see the section of the function code F04.
H54, H55
H56
H57 to H60
Acceleration/Deceleration Speed Time (Jogging) (See F07)
Forcible Stop Deceleration Time
Acceleration/Deceleration Time 1st to 2nd S-curve Range
For details of acceleration/deceleration time (jogging), forcible stop deceleration time, 1st and 2nd S-curve in
acceleration/deceleration, see the section of the function code F07.
H61
UP/DOWN Control, Initial Value Selection (See F01)
For details of UP/DOWN control, initial value selection, see the section of the function code F01.
