5.4 Details of Function Codes
5-212
If the motor switching is set, the function codes in Table 5.4-148 are switched. Note that the function codes
listed in Table 5.4-149 are unavailable when any of the 2nd to 4th motors are selected.
When the parameter switching is set, function codes with "
{" marks, which are objective for parameter
switching, switch. For other parameters, ones in the 1st motor column remain effective, and there is no
function code that are cancelled in the 2nd to 4th motors.
Table 5.4-148 Function Codes to be Switched
Function Code
Name
1st motor 2nd motor 3rd motor 4th motor
Object of
parameter
switching
Maximum output frequency F03 A01 b01 r01
Base frequency F04 A02 b02 r02
Base frequency voltage F05 A03 b03 r03
Maximum output voltage F06 A04 b04 r04
Torque boost F09 A05 b05 r05
Electronic Thermal Motor Protect
(Characteristics Selection)
F10 A06 b06 r06
(Operation level) F11 A07 b07 r07
(Thermal Time Constant) F12 A08 b08 r08
DC brake -> (Start Frequency) F20 A09 b09 r09
(Operation level) F21 A10 b10 r10
(Time) F22 A11 b11 r11
Starting frequency F23 A12 b12 r12
Load selection/Auto torque boost
/Auto energy saving operation
F37 A13 b13 r13
{
Select control method F42 A14 b14 r14
Motor constant (No. of poles) P01 A15 b15 r15
(Capacitance) P02 A16 b16 r16
(Rated current) P03 A17 b17 r17
(Auto-tuning) P04 A18 b18 r18
(Online tuning) P05 A19 b19 r19
(No-load current) P06 A20 b20 r20
(%R1) P07 A21 b21 r21
(%X) P08 A22 b22 r22
(Slip compensation gain [drive]) P09 A23 b23 r23
{
(Slip compensation response time) P10 A24 b24 r24
{
(Slip compensation gain [brake]) P11 A25 b25 r25
{
(Rated slip) P12 A26 b26 r26
(Iron loss coefficient 1) P13 A27 b27 r27
(Iron loss coefficient 2) P14 A28 b28 r28
(Iron loss coefficient 3) P15 A29 b29 r29
(Magnetic saturation factor 1) P16 A30 b30 r30
(Magnetic saturation factor 2) P17 A31 b31 r31
(Magnetic saturation factor 3) P18 A32 b32 r32
(Magnetic saturation factor 4) P19 A33 b33 r33
(Magnetic saturation factor 5) P20 A34 b34 r34
(Magnetic saturation extension factor "a") P21 A35 b35 r35
(Magnetic saturation extension factor "b") P22 A36 b36 r36
(Magnetic saturation extension factor "c") P23 A37 b37 r37
Motor selection P99 A39 b39 r39
Slip Compensation
(Operating conditions selection)
H68 A40 b40 r40
{
Current Fluctuation Damping Gain H80 A41 b41 r41
{
Speed control (Speed command filter) d01 A43 b43 r43
{
(Speed detection filter) d02 A44 b44 r44
{
P (Gain) d03 A45 b45 r45
{
