5.4 Details of Function Codes
5-267
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U00 to U91
y codes
To configure the above customizable logic, set function codes as follows. (Timer selection) and (Time
setting) require no modification unless otherwise required.
Table 5.4-192
Function Code Setting
Data
Setting Contents Remarks
E98 Terminal FWD (Function selection) 98 Run forward, stop
command
FWD
U00 Customizable logic (Operation
selection)
1 Enable
U01 (Input 1) 4010 FWD terminal input
signal
FWD
U02 (Input 2) 3007 Output of step 7
(negative logic)
SO07
U03
Customizable logic:
Step 1
(Logic circuit) 2 ANDing +
General-purpose timer
U06 (Input 1) 2001 Output of step 1 SO01
U08 (Logic circuit) 1 Through output +
General-purpose timer
Operation
selection
U09 (Timer selection) 1 On-delay timer
U10
Customizable logic:
Step 2
(Timer setting) Any value Stage 1 run time
U11 (Input 1) 3002 Output of step 2
(negative logic)
SO02
U13 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U14 (Timer selection) 3 Pulse (one-shot)
U15
Customizable logic:
Step 3
(Timer setting) Any value Stage 2 run time
U16 (Input 1) 2003 Output of step 3 SO03
U18 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U19 (Timer selection) 3 Pulse (one-shot)
U20
Customizable logic:
Step 4
(Timer setting) Any value Stage 3 run time
U21 (Input 1) 2004 Output of step 4 SO04
U23 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U24 (Timer selection) 3 Pulse (one-shot)
U25
Customizable logic:
Step 5
(Timer setting) Any value Stage 4 run time
U26 (Input 1) 2003 Output of step 3 SO03
U27 (Input 2) 2005 Output of step 5 SO05
U28
Customizable logic:
Step 6
(Logic circuit) 3 ORing +
General-purpose timer
U31 (Input 1) 2004 Output of step 4 SO04
U32 (Input 2) 2005 Output of step 5 SO05
U33
Customizable logic:
Step 7
(Logic circuit) 3 ORing +
General-purpose timer
U71 Customizable logic
output signal 1
(Output selection) 6 Output of step 6 SO06 SS1 command
U72 Customizable logic
output signal 2
6 Output of step 6 SO06 RT1 command
U73 Customizable logic
output signal 3
7 Output of step 7 SO07 SS2 command
U74 Customizable logic
output signal 4
7 Output of step 7 SO07 RT2 command
