11.4 Option
11-27
Chapter 11 SELECTING PERIPHERAL EQUIPMENT
(3) Specifications
Table 11.4-1 Generated Loss in Braking Unit
Model name Generated loss (W)
BU37-2C
40
BU55-2C 50
BU90-2C 60
BU37-4C 35
BU55-4C 40
BU90-4C 50
BU132-4C 60
BU220-4C 80
*10% ED
Table 11.4-2 Braking Unit and Braking Resistor (Standard Model) for HD-Mode Inverters
Note: A box () in the above table replaces an alphabetic letter depending on the enclosure.
S (Basic type), E (EMC filter built-in type), H (DC reactor built-in type)
