Table 11.4-23 AC Reactor (ACR) Specifications
Reactance
(mΩ/phase)
Power supply
voltage
Nominal
applied
motor
(kW)
Inverter type Mode
AC Reactor
type
Rated
current
(A)
50 Hz 60 Hz
Wirewound
resistor
(mΩ)
Generated
loss
(W)
0.4 FRN0.4G1-2J ACR2-0.4A 3 917 1100 - 10
0.75 FRN0.75G1-2J ACR2-0.75A 5 493 592 - 12
1.5 FRN1.5G1-2J ACR2-1.5A 8 295 354 - 14
2.2 FRN2.2G1-2J ACR2-2.2A 11 213 256 - 16
3.7 FRN3.7G1-2J
HD
ACR2-3.7A 17 128 153 - 23
5.5 HD ACR2-5.5A 25 87.7 105 - 27
FRN5.5G1-2J
LD
7.5
HD
ACR2-7.5A 33 65 78 - 30
FRN7.5G1-2J
LD
11
HD
ACR2-11A 46 45.5 54.7 - 37
FRN11G1-2J
LD
15
HD
ACR2-15A 59 34.8 41.8 - 43
FRN15G1-2J
LD
18.5
HD
ACR2-18.5A 74 28.6 34.3 - 51
FRN18.5G1-2J
LD
22
HD
ACR2-22A 87 24 28.8 - 57
FRN22G1-2J
LD
30
HD
ACR2-37 200 10.8 13 0.5 28.6
FRN30G1-2J
LD
37
HD
ACR2-37 200 10.8 13 0.5 40.8
FRN37G1-2J
LD
45
HD
ACR2-55 270 7.5 9 0.375 47.1
FRN45G1-2J
LD
55
HD
ACR2-55 270 7.5 9 0.375 66.1
FRN55G1-2J
LD
75
HD
ACR2-75 390 5.45 6.54 0.25 55.1
FRN75G1-2J
LD
90
HD
ACR2-90 450 4.73 5.67 0.198 61.5
Three-phase
200 V
110
FRN90G1
-2J
LD ACR2-110 500 4.25 5.1 0.18 83.4
(Note 1) A box () in the above table replaces an alphabetic letter depending on the enclosure.
S (Basic type), E (EMC filter built-in type), H (DC reactor built-in type)
(Note 2) Generated losses listed in the above table are approximate values that are calculated according
to the following conditions:
• The power supply is three-phase 200 V/400 V, 50 Hz with 0% interphase voltage unbalance
ratio.
• The power supply capacity uses the larger value of either 500 kVA or 10 times the rated
capacity of the inverter.
• The motor is a 4-pole standard model at full load (100%).
To Next Page
