11.4 Option
11-64
Rated output current
The table below shows the rated output current for three-phase, 200 V class series of LD (Low Duty)-mode
inverters for light duty load applications.
Table 11.4-31
Item Specifications
Applicable inverter type (FRNG1S-2) 5.5 7.5 11 15 18.5 22
Output ratings Rated current (A) 29 42 55 68 80 107
Surrounding temperature
-10 to +40°C
Number of option cards (printed circuit boards) mountable on the inverter
The inverter equipped with the IP40 kit can accept only one more option card except the relay output
interface card (while OPC-G1-RY, the relay output interface card, allows for installing two cards).
Any type of option cards is compatible with this IP 40 kit. The option connection port(s) to be used differ
depending on the specifications of each option card.
(4) Changing the function code setting
Select IP40 by setting Bit 7 (Switch IP20/IP40) of function code H98 (Protection/Maintenance Function
(Mode selection)).
For protection coordination, it is necessary to switch to the protection level suitable for the protection
rating.
