12.2 Standard Model 2 (EMC Filter Built-in Type)
12-8
LD (Low Duty)-mode inverters for light load (5.5 to 75 kW)
Item Specifications
Type (FRN***G1E-4J) 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Nominal applied motor
(kW)
*1
(Output rating)
－ 7.5 11 15 18.5 22 30 37 45 55 75 90
Rated capacity (kVA)
*2
－ 12 17 22 28 33 45 57 69 85 114 134
Rated voltage (V)
*3
－ Three-phase 380 to 480 V (with AVR function)
Rated current (A) － 16.5 23 30.5 37 45 60 75 91 112 150 176
Output ratings
Overload capability － 120%-1 min
Voltage, frequency － 380 to 480 V, 50/60 Hz
*9
Allowable
voltage/frequency
－ Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less)
*5
, Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
－ 10 15 20 25 30 40 48 58 71 96 114
Torque (%)
*7
－ 70% 15% 7 to 12%
Braking transistor － Built-in －
Built-in braking resistor
Braking time (s)
－ 3.7 s 3.4 s －
Braking
Duty cycle (%ED) － 2.2 1.4 －
EMC filter －
Compliant with EMC Directives, Emission and Immunity: Category C3 (2nd Env.)
(EN61800-3:2004)
DC reactor (DCR)
*8
－ Option
Provided as
standard
Applicable safety
standards
－ UL508C, C22.2 No.14, IEC/EN61800-5-1:2007
Enclosure (IEC60529) － IP20, UL enclosed type IP00, UL open type
Cooling method － Fan cooling
Weight / Mass (kg) － 6.8 6.9 6.2 10.5 10.5 11.2 26 27 32 33 42
(90 to 630 kW)
Item Specifications
Type (FRN***G1E-4J) 90 110 132 160 200 220 280 315 355 400 500 630
Nominal applied motor
(kW)
*1
(Output rating)
110 132 160 200 220 280 355 400 450 500 630 710
Rated capacity (kVA)
*2
160 192 231 287 316 396 495 563 640 731 891 1044
Rated voltage (V)
*3
Three-phase 380 to 480 V (with AVR function)
Rated current (A) 210 253 304 377 415 520 650 740 840 960 1170 1370
Output ratings
Overload capability 120%-1 min
Voltage, frequency
380 to 440 V, 50 Hz
380 to 480 V, 60 Hz
Allowable
voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less)
*5
, Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
140 165 199 248 271 347 436 489 547 611 773 871
Torque (%)
*7
7 to 12%
Braking transistor －
Built-in braking resistor
Braking time (s)
－
Braking
Duty cycle (%ED) －
EMC filter Compliant with EMC Directives, Emission and Immunity: Category C3 (2nd Env.) (EN61800-3:2004)
DC reactor (DCR)
*8
Provided as standard
Applicable safety
standards
*10
UL508C, C22.2 No.14, IEC/EN61800-5-1:2007
Enclosure (IEC60529) IP00, UL open type
Cooling method Fan cooling
Weight / Mass (kg) 62 64 94 98 129 140 245 245 330 330 530 530
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 220 V for 200 V class series and 440 V for 400 V class
series.
*3 Output voltage cannot exceed the power supply voltage.
*5 Voltage unbalance (%) = Max. voltage (V) - Min. voltage (V) / Three-phase average voltage (V) × 67 (IEC/EN61800-3）
If this value is 2 to 3%, use an optional AC reactor (ACR).
*6 Required when a DC reactor (DCR) is used.
*7 Average braking torque for the motor running alone. (It varies with the efficiency of the motor.)
*8 For inverters with a capacity of 55 kW, a DCR is provided as standard or option for LD or HD mode, respectively.
*9 380 to 440 V, 50 Hz; 380 to 480 V, 60 Hz
*10 Inverters with the following capacity are not compliant with the safety standards C22.2 No.14.
FRN160G1-4J to FRN220G1-4J, FRN355G1-4J, FRN400G1-4J
