App. B Japanese Guideline for Suppressing Harmonics by Customers Receiving High Voltage or Special High Voltage
A-14
Table B-2 "Input Rated Capacities" of General-purpose Inverters Determinedby the Applicable Motor Ratings
Applicable motor
rating (kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
200 V 0.57 0.97 1.95 2.81 4.61 6.77 9.07 13.1 17.6 21.8Pi
(kVA)
400 V 0.57 0.97 1.95 2.81 4.61 6.77 9.07 13.1 17.6 21.8
Applicable motor
rating (kW)
22 30 37 45 55 75 90 110 132 160
200 V 25.9 34.7 42.8 52.1 63.7 87.2 104 127 Pi
(kVA)
400 V 25.9 34.7 42.8 52.1 63.7 87.2 104 127 153 183
Applicable motor
rating (kW)
200 220 250 280 315 355 400 450 500 630
200 V Pi
(kVA)
400 V 229 252 286 319 359 405 456 512 570 718
(2) Values of "Ki (conversion factor)"
Depending on whether an optional ACR (AC reactor) or DCR (DC reactor) is used, apply the
appropriate conversion factor specified in the appendix to the guideline. The values of the conversion
factor are listed in Table B-3.
Table B-3 "Conversion Factors Ki" for General-purpose Inverters Determined by Reactors
Circuit
category
Circuit type
Conversion
factor Ki
Main applications
w/o a reactor K31 = 3.4 • General-purpose
inverters
w/ a reactor (ACR) K32 = 1.8 • Elevators
w/ a reactor (DCR) K33 = 1.8 • Refrigerators, air
conditioning
systems
3
3-phase bridge
(capacitor smoothing)
w/ reactors (ACR and DCR) K34 = 1.4 • Other general
appliances
Some models are equipped with a reactor as a standard accessory.
[2] Calculation of Harmonic Current
(1) Value of "input fundamental current"
• When you calculate the amount of harmonics according to Table 2 in Appendix of the Guideline, you
have to previously know the input fundamental current.
• Apply the appropriate value shown in Table B-4 based on the kW rating of the motor, irrespective of the
inverter type or whether a reactor is used.
If the input voltage is different, calculate the input fundamental current in inverse proportion to the
voltage.
Table B-4 "Input Fundamental Currents" of General-purpose Inverters Determined by the Applicable Motor Ratings
Applicable motor rating (kW) 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
200 V 1.62 2.74 5.50 7.92 13.0 19.1 25.6 36.9 49.8 61.4Input fundamental
current (A)
400 V 0.81 1.37 2.75 3.96 6.50 9.55 12.8 18.5 24.9 30.7
6.6 kV converted value (mA) 49 83 167 240 394 579 776 1121 1509 1860
Applicable motor rating (kW) 22 30 37 45 55 75 90 110 132 160
200 V 73.1 98.0 121 147 180 245 293 357 Input fundamental
current (A)
400 V 36.6 49.0 60.4 73.5 89.9 123 147 179 216 258
6.6 kV converted value (mA) 2220 2970 73.5 4450 5450 7450 8910 10850 13090 15640
Applicable motor rating (kW) 200 220 250 280 315 355 400 450 500 630
200 V Input fundamental
current (A)
400 V 323 355 403 450 506 571 643 723 804 1013
6.6 kV converted value (mA) 19580 21500 24400 27300 30700 34600 39000 43800 48700 61400
