Fuji Xerox DocuCentre-V C2263 User Manual

Machine Components
59
Product Overview
2
3 Drum cartridges (R1
(Black), R2 (Cyan), R3
(Magenta), R4
(Yellow))
Contains photoconductors and development units. Drum
cartridges are arranged in order R1 (Black), R2 (Cyan), R3
(Magenta), R4 (Yellow) from the left as you face the
machine.
Note
z
The drum cartridge is always marked with R1, R2, R3, or R4.
Make sure to align the drum cartridge R1, R2, R3, or R4 with
the corresponding slot. Otherwise, the drum cartridge cannot
be inserted into the machine.
4 Cleaning bar Used for cleaning the exposure unit when density
unevenness or stripes appear on copied or printed outputs
due to dirt in the exposure unit.
5 Drum cartridge cover Open this cover when replacing a drum cartridge or
cleaning the interior of the machine.
6 Drum cartridge
release lever
Unlock this lever when replacing a drum cartridge.
7 Waste toner container
(R5)
Collects waste toner.
8 Fusing unit (R8) Fuses toner on paper. Do not touch this unit as it is
extremely hot.
No. Component Function

Fuji Xerox DocuCentre-V C2263 Specifications

General

Print Resolution	1200 x 2400 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan, Fax
Memory (Standard)	1GB
Duplex Printing	Yes
Fax Transmission Speed	33.6 kbps
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Paper Size	A4, A5, B5
Hard Disk Drive	160 GB
