16 Maintenance
286
Inserting the New Drum Cartridge
1. Remove the new drum cartridge from the box.
2. Undo the sealing tape and
carefully pull it out to remove the
black protective sheet from the
cartridge.
3. Place the cartridge in position as
shown and slide it into the
machine until it clicks.
4. Pull out the cartridge tape
completely without breaking.
5. Push the cartridge again to
make sure that it is properly set
in the machine.
6. Close the Cover A until it
latches, and then close the
bypass tray.
C
C
C
