TX100 S3 Upgrade and Maintenance Manual 113
Hard disk drives
7.2.5 SATA cabling to onboard controller
Figure 49: Connecting SATA cables to HDD1/2
Ê Connect the SATA cable connected to SATA 1 to the HDD 1 (1).
Ê Connect the SATA cable connected to SATA 2 to the HDD 2 (2).
