Fujitsu PRIMERGY TX100 S3 - Basic Information

236 Upgrade and Maintenance Manual TX100 S3
Accessible drives
12.1 Basic information
Mounting order for accessible drives
PRIMERGY TX100 S3 server offers two 5.25-inch accessible drive bays for
optical disk drives and backup drives:
Figure 145: Accessible drives mounting order
Sequence Accessible drive Bay Max. #
1
Optical disk drive
or slimline optical disk drive
Bay 1 1
2 Backup drive LTOx Bay 2 1
3 RDX backup drive Bay 2 1
Table 6: Accessible drive mounting sequence
/
