TX100 S3 Upgrade and Maintenance Manual 337
16 Appendix
16.1 Mechanical overview
16.1.1 Server front
Figure 234: PRIMERGY TX100 S3 front
Pos. Component
1 Optical disk drive
2 Slot for Backup drive
3 On/Off button
4 Front USB connectors
/
