TX100 S3 Upgrade and Maintenance Manual 293
System board and components
14.2 Trusted Platform Module (TPM)
14.2.1 Installing the TPM
14.2.1.1 Required tools
● Preliminary and concluding steps: tool-less
● Installing the TPM:
– Bit screw driver
– TPM bit insert (*)
(*) For the Japanese market:
– TPM module fixing tool (S26361-F3552-L909)
14.2.1.2 Preliminary steps
Before installing the TPM, perform the following steps:
Ê Shut down the server as described in section "Shutting down the server" on
page 42.
Ê Remove the AC power cord from the cable tie and disconnect it from the
system as described in section "Disconnecting power cord" on page 43.
Ê Open the side cover as described in section "Removing the side cover" on
page 45.
Field Replaceable Units (FRU)
Average hardware task duration: 5 minutes
Average software task duration: 5 minutes
