Fujitsu PRIMERGY TX100 S3 Maintenance Manual

TX100 S3 Upgrade and Maintenance Manual 339
Appendix
16.1.3 Server interior
Figure 236: PRIMERGY TX100 S3 server interior
Pos. Component
1 Expansion card slots
2 Processor / CPU heat sink / CPU fan
3 HDD 2
4 TPM board (if installed)
5 CMOS battery (not visible, located under the system fan 2)
6 HDD 1
7 System fan 1 (fan 3 on the SEL)
8 BBU/FBU (if installed)
9 HDD 3
10 HDD 4
:;
<
=
/ 0
9
5
6
7
8
3 421
