Fujitsu PRIMERGY TX100 S3 Maintenance Manual

TX100 S3 Upgrade and Maintenance Manual 115
Hard disk drives
Figure 51: Connecting SATA cables to the system board
Ê Connect the following cables to the system board.
1 SATA cable to connector SATA 1
2 SATA cable to connector SATA 2
3 SATA cable to connector SATA 3
4 SATA cable to connector SATA 4
Ê For further cabling information, please refer to section "Cabling" on
page 321.
/
