132 Upgrade and Maintenance Manual TX100 S3
System fan modules
Figure 63: Disconnecting the fan cable
Ê Disconnect the fan cable from system board connector FAN1 SYS.
Figure 64: Cable clamp of the fan cable
Ê Open the cable clamp and remove the fan cable.
