Fujitsu PRIMERGY TX100 S3 Maintenance Manual

TX100 S3 Upgrade and Maintenance Manual 149
Expansion cards and backup units
Expansion card overview
I For the latest information on supported expansion cards, refer your
server’s hardware configurator available online at the following address:
for the EMEA market:
http://ts.fujitsu.com/products/standard_servers/tower/primergy_tx100s3.html
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
1. Controller for special
slots
PCI bus type Max pcs per
system
Preferred slot Forbidden
slot
1 2 3
S26361-D2616-A** (boot
controller)
PCIe 1 3 1, 2, 4
S26361-D3116-B** PCIe 1 3 1, 2, 4
2. Graphic controller PCI bus type Max pcs per
system
Preferred slot Forbidden
slot
1 2 3
Nvidia NVS300 PCIe x1 PCIe 1 2 1, 3, 4
3. PCI-Express
controller
PCI bus type Max pcs per
system
Preferred slot Forbidden
slot
1 2 3
S26361-D3305-A10-1
(USB3.0 PCIe)
PCIe 1 1 2, 3, 4
Intel Pro 1000CT
Desktop Adapter PCIe x1
PCIe 2 1 2 4 3
FTS: S26361-D2735
(Kawela)
Intel Dual Port PCIe x4
PCIe 1 2 4 1 3
