Fujitsu PRIMERGY TX100 S3 Maintenance Manual

170 Upgrade and Maintenance Manual TX100 S3
Expansion cards and backup units
Figure 92: Installing the BBU holder (B)
Ê Insert the BBU holder into the chassis so that the three bolts rest in the wide
ends of the keyhole slots on the bottom side of the BBU holder.
Ê Slide the BBU holder down until the locking handle of the BBU holder
properly snaps in place (see circle).

Fujitsu PRIMERGY TX100 S3 Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX100 S3
Category	Server
Language	English
