18 Upgrade and Maintenance Manual TX100 S3
Introduction
Model lines for TX100 S3
There are two model lines for the TX100 S3 server:
– TX100 S3
– TX100 S3p
The following table provides an overview of the different features:
I For the European market:
You can identify the model line by the model name "TX100 S3p" printed
on the identification rating plate.
I For the Japanese market:
"TX100 S3p" is not used as the model name in the Japanese market.
You can identify the model line by the product number; The product
number "PYT10Pxxx" means TX100 S3p.
TX100 S3 TX100 S3p
System board D3009-Axx D3009-Bxx
Processors Intel
®
XEON
®
E3-1200
processor series
Intel
®
Pentium
®
/ Celeron
®
processor series
Intel
®
Core™ i3-2100
processor series
Intel
®
XEON
®
E3-1200v2
processor series
Intel
®
Pentium
®
/ Celeron
®
processor series
Intel
®
Core™ i3
processor series
Main Memory DDR3 UDIMM with 1333 MHz
speed
up to 21 GB/s bandwidth in
dual channel mode and 10.6
GB/s in single channel mode
DDR3 UDIMM with 1600 MHz
speed
up to 25.6 GB/s bandwidth in
dual channel mode and 12.8
GB/s in single channel mode
PCI slots 2x PCIe x8 Gen 2
(one mechanical x16)
1x PCIe x4 Gen 2
(mechanical x4 notched)
1x PCIe x1 Gen 2
(mechanical x4 notched)
2x PCIe x8 Gen 3
(one mechanical x16)
1x PCIe x4 Gen 2
(mechanical x4 notched)
1x PCIe x1 Gen 2
(mechanical x4 notched)
Table 1: Differences between TX100 S3 and TX100 S3p
