TX100 S3 Upgrade and Maintenance Manual 327
Cabling
Figure 225: USB 3.0 RDX drive cabling with USB 3.0 cable
PWR
FAN1 SYS
HDD
ACTIVITY
Front panel
SATA
PWR
PC2009
TPM
SATA5
FAN
CPU
FAN2
SYS
SATA1
SATA3
Front USB
Optical drive (top)
Front panel
On/off + HDD access
USB 3.0 DAT/RDX
drive (bottom)
USB 3.0 interface card
