Fujitsu PRIMERGY TX100 S3

TX100 S3 Upgrade and Maintenance Manual 55
Basic hardware procedures
Figure 13: Connecting cables to the optical disk drive
Ê Connect cables to the optical disk drive.
1 Power cable connector P8 (see figure figure 227 on page 329)
2 SATA cable
/
