Name: Funkwerk elmeg CS400xt
Brand: Funkwerk
Rating: 4 (1 reviews)

To Next Page

To Previous Page

Activate call forwarding

Ms s s s

Setting Call rerout. delayed

busy Fixed

MSN-1...

MSN-10

Dial call number

Deactivating call rerouting

Ms s ssO

Setting Call rerout. Off

MSN-1...

MSN-10

Silent signalling

Quiet No/ok/Ringing signal off

Dialing from caller list, telephone directory or short dialing memory

s<>

Caller list

Tel. drctry/VIP

Select entry

Brief description of functions

118

Default Chapter3
- Table of Contents3
Description and Installation10
- CS400 / Cs400Xt10
- Configuring Emergency Operation (Ptmp and Ptp Connections)11
- Configuring Emergency Operation at a Point-To-Point (Ptp) Connection11
- Making Calls During Emergency Operation at a Point-To-Multipoint Connection11
- Making Calls at Emergency Power Supply Mode on a Point-To-Point Connection11
Cs41011
Cs410-U11
Elmeg IP-S40011
- Setting Up/ Configuring the System Telephone11
System-Telephone Extension Modules12
- Up0/S0-Module (CS410 Only)12
- Answering Machine Module (Only CS410, CS410-U)12
- Additional »T400« Keyboard12
- Additional »T400/2« Keyboard12
Safety Notes12
- Plug-In Power Supply13
- Elektrostatic Charges (Protection against Electrostatic Charges)13
- Unpacking and Placing the Telephone13
- Unpacking13
- Placing the Telephone13
- Cleaning the Telephone13
- Connecting the Telephone (Connecting and Handset Cords)14
- Connecting the Handset Connecting Cord14
- Connecting the Connecting Cord14
- Important Notes for Connecting the Telephone to the Up014
- Connecting and Configuring a Headset (Not Included in the Scope of Supply)15
- Connecting a Headset15
- Further Settings When Using a Headset16
Connecting the Telephone to a PC16
- Connecting the PC Connection Cable (USB)16
- CS 410, CS 410-U Connecting the Audio Cable (Audio in / Audio Out)17
- IP-S400 Audio in / Audio out17
Elmeg IP-S400 at the Ethernet-Port17
- PIN Assignment for Poe18
- Connecting to and Operating the System Telephone at the Pabx System (Basic Function Including DHCP)18
Changing the Label19
Pictographs20
Setting the Display Language20
Telephone Display and Buttons21
- Telephone Display22
- Special Feature for Displaying Lists in the Display23
- Special Feature for Changing Existing Entries23
- Key Assignments for Entering Texts24
- Input Mode for Entering Letters24
- Call Signaling24
Contents25
- Function Keys and Leds25
- LED Call Signaling and Answering Machine25
- Acknowledegement Signals25
- Positive Acknowledgement Signal (1 Long Tone)25
- Negative Acknowledgement Signal (3 Short Beeps)25
- Displays for Programmed Features25
- Displays26
- Configured Function26
Making Calls27
Starting a Call27
- Dial Number - no Correction Possible27
- Dial Call Number - Correction Possible27
- Other Options for Dialing Without Lifting the Handset27
- Dialing from the Pabx Telephone Directory28
- Dialing from the Telephone Directory28
- Dialing from the VIP Memory28
- Direct Dial-In Using Function Keys28
- From Dialing from the Caller/Memo List28
Accepting / Rejecting a Call29
Call Deflection29
No Number Transmission (Anonymous Call)29
Starting a Call with a Fixed Extension Number (MSN)30
Redialing30
- Extended Last Number Redial30
- Deleting a Telephone Number from Extended Redialing or Save as a Memo31
- Importing Numbers from Extended Redialing into the Telephone Directory31
- Automatic Redialing31
- Suspending Automatic Redialing32
- Deactivating Automatic Redialing32
Microphone Activation/Deactivation, Open Listening and Hands-Free Calling32
- Mute On/Off32
- Speaker Function32
- Hands Free Calling33
Headset Use33
- Activating and Deactivating the Headset33
- Activating and Deactivating Open Listening While Using the Headset33
Announcement33
Intercom34
Automatic Completion of Call35
- Automatical Recall to Busy Subscriber (CCBS)35
- Automatic Completion of Calls on no Reply (CCNR)35
- Programming Completion of Call to Busy Subscriber35
- Viewing and Clearing Call-Back Calls36
Parking a Call (Not with IP-S400)36
- Park36
- Unparking36
Tracing (MCID)(Only Via ISDN Cord)36
- Malicious Call Identification During Ongoing Call37
- After the Caller Has Hung up the Handset37
Keypad and Tone Frequency Dialing (DTMF Dialing)37
- Keypad37
- Tone Dialing (Dtmf Dialing)37
Conducting Calls with Several Subscribers38
Call Waiting38
Inquiry Call38
- Transferring a Call to a Busy Subscriber38
Call Switching39
Broker's Call39
Three-Party Conference39
Telephone Operation41
Telephone Directory41
- Settings for Telephone Book Entries41
- Name and Number41
- Outgoing Number (MSN Assignment)41
- Special Dial Tone41
- Infotext41
- Add an Entry to the Telephone Directory42
- Editing Phone Directory Entries42
- Deleting a Phone Directory Entry42
- Programming Special Dial Tones (VIP-Tones) for Telephone Directory Entries43
- Programming an Info Text for a Telephone Book Entry43
VIP-Memory43
- Programming VIP Entries43
- Editing VIP Entries44
Caller- and Memo List44
- Caller List45
- Memo List45
- SMS / UUS1 Messages45
- UUS1 Inhibiting Filter45
- Viewing the Caller List46
- Further Information about a Call / Memo46
- Further Information about a Text Message (SMS / UUS1)47
- Deleting the Caller / Memo List48
- Deleting an Entry48
- Deleting All Calls48
- Entering the Number of the Caller in the Phone Book of the Phone48
- Entering a Memo48
- The Following Example Describes How to Add a New Number as a Memo49
SMS and UUS1 Text Messages49
- SMS Text Messages (Subject to Terms of Network Provider)49
- UUS1 Text Messages50
- Creating and Sending Text Messages Creating and Sending Text Messages50
- Example: Creating a UUS1 Text Message50
- Important Notes for Entering Numbers with SMS Transmission51
- Sending an Interlaced SMS51
- Viewing Newly Received Text Messages51
- Viewing Received or Sent Text Messages51
- Example: Reading a Received UUS1 Message52
- Permanently Stored Text Messages (UUS1 Only)52
- Automatic Sending of Text Messages (UUS1 Only)53
- Configuring the Text Message Reception Mode (UUS1 Only)53
Contents54
- Error When Sending or Receiving an SMS54
- Error While Sending an SMS54
- Error While Receiving an SMS54
Silent Signalling54
Monitoring Costs55
- Procedures for Charge Rate Transmission55
Viewing and Deleting Costs55
- Viewing/Deleting Costs for the Last Call55
- Viewing and Deleting Total Costs56
- Viewing/Deleting Costs for Specific Extension Numbers (MSN)56
Setting the Tariff Factor and the Currency56
Programming a Charge Limit for an Extension Number57
Enabling or Inhibiting an Extension Number (MSN) for Outgoing Calls57
Communication and Charge Displays58
- The Following Displays Are Possible During a Call58
- Displaying Information During a Call59
- Programming Calling Line Identification Mode (CLIP/CLIR/COLP/COLR)59
System Telephony61
Function Keys61
- Function Key Examples61
- Direct Dialing Buttons61
- DTMF/ Keypad Sequences61
- Defining the MSN Extension Number for the Next Call (MSN Assignment)61
- Line Keys61
- Trunk Group Buttons61
- Extension Keys61
- Connection Keys62
- System-Parked Inquiry« Button62
- Team Keys62
- Team Log-On/Off62
- Day/ Night Modes63
- Announcement63
- Message Enable On/Off63
- Intercom63
- Intercom Enable On/Off63
- Boss/Sec.-Function63
- Xfer Secretary63
- Call Filter63
- Call Rerouting63
- Direct Dial-In63
- Extension Key for an Answering Machine64
- Voice Mail-Button64
- User On/Off Button (Sertaste Ein/Aus (Programming the System Telephone's MSN Extension Number)64
- Status Info Button64
- Macro Functions64
- LED Functions65
- Programming a Function Key65
- Using the Function Key66
- Important Notes for LED Functions66
System Menu at a Pabx with System Telephony66
- Accessing the System Menu for PABX Systems66
Configuring and Setting up the System Telephone68
Extended Configuration68
Acoustic69
- Headset69
- Speaker69
- Call Waiting70
- Acknowledgement Signals70
- Idle71
- Handset71
- Notice Tone (Announcement and Intercom)72
- Announcement72
- Intercom72
- Answering Machine72
- Date73
- Audio-Out73
- Listening to Audio-In over the Speaker73
Settings74
- Direct Call74
- Call Rerouting (Call Forwarding)75
- Special Features for the Swiss Version76
- Call Waiting77
- Display Contrast78
- Appointment78
- Deactivating an Appointment Reminder79
- Auto-Answer79
- Headset79
- Operation80
- Setting the Time80
- Call Filter81
- Call Filter Operating Modes81
- Programming Filter Numbers81
- The Following Example Describes How to Enter a New Filter Number81
Configuration83
- Inhibit83
- Pin83
- Menu84
- Outgoing84
- List85
Display85
- Call Number85
- Language86
- Conversation86
- Call-Parking (Default Setting)87
- Connection to a Pabx87
- MSN (Extension Numbers)88
- Entering a Name for an Extension Number90
- Programming a Specific PIN for an Extension Number (MSN)91
Setting up the IP-S40091
- Log-On92
- Entering the IPS Log-In PIN92
- Entering the »Sys-Server Log-In PIN for the IPS92
- Configuring the IP-S400 Without DHCP93
Programming Numbers96
- Programming Function Keys96
Function Keys and Further Entries96
Function96
Displays96
Further Entries96
- Commands and Keys for Macro Programming97
- The Following Commands Are Available for Macro Programming97
- Key Assignments for Macro Programming98
- Macro Programming Examples99
Service100
- Name100
- Sms100
- Version101
- Data101
- Software102
- Initiating Download of New Firmware on the Phone103
- Telephone BIOS104
- The Following Functions Are Available in the Telephone's BIOS104
- Downloading New Firmware Via the PC Port104
- Downloading New Firmware Via the ISDN Connection104
- Country104
- Country-Specific Settings104
Telephone and PC106
CTI / TAPI Using the Phone's USB Port106
CAPI Using the Telephone's USB Port106
- Fax and Data Services (Not Included in the Delivery)106
- Internet Access106
Audio Applications Using the Phone's Audio Jacks107
Contents of the WIN-Tools CD-ROM107
- Programs for Telephone Configuration (WIN-Tools)107
- Application Programs107
- Drivers107
- Important Note for Installation of the CAPI Drivers108
Installing the Programs from CD-ROM108
- PC Requirements108
- Installation Sequence108
Default Telephone Settings110
Menu of the Telefone112
- Menu »Configuration112
- Menu»Acoustic113
- Menu »Settings114
- Menu »Program Nos115
Technical Specifications116
- Up0-Connection (CS410-U)116
- Audio Connections116
- Ethernet-Port116
- ISDN Port (CS410, CS400)119
- USB Port119
- Brief Description of Functions126

Questions and Answers:

Need help?

Do you have a question about the Funkwerk elmeg CS400xt and is the answer not in the manual?

Funkwerk elmeg CS400xt Specifications

General

Brand	Funkwerk
Model	elmeg CS400xt
Category	Telephone
Language	English

Related product manuals

Funkwerk elmeg CS410

129 pages

Funkwerk elmeg IP-S400

129 pages

Funkwerk elmeg CS400xt User Manual

Table of Contents

Questions and Answers:

Funkwerk elmeg CS400xt Specifications

Related product manuals
