ConnecttheUSBcord(4)asshowninfigure5(PC-socket). PlugtheUSBconnector(typeA)intothecorre
-
spondingsocketofyourPCandtheUSBconnector(typeB)intotheUSBsocketonthebackofthetelephone
(1). The telephoneis automatically detected by the PC,provided that both devices (telephoneand PC) are
switched on.
Installat ion of a device driver is started automaticallythe first timeyou connect thetelephone
to thePC. InserttheWIN-Tools CD-ROM supplied with the telephone and follow the instruc
-
tions displayed on the screen.
You will need a hub(USB distributor) ifyou planto useseveral USBterminal devicesat yourPC. Connect
thehubto theUSBport ofthe PC.YoucanthenconnectotherUSBterminaldevices,includingthetelepho
-
ne to the hub.
CS 410, CS 410-U connecting the audio cable (Audio in / Audio Out)
Thetelephoneisequippedwithaninput(2)and anoutput(3)foraudiosignals. Boththeseportshavea3.5
mmstereosocket. Whenusingtheoptional answeringmachinemodule,youcanconnectthetelephonevia
these ports to the PC sound card in order to upload announcements into the phone or save recorded
messages on the PC.
YoucanalsousespecifictelephonefeatureswiththeAudio-Outoutput(seepage64). Connectthespeakers
(5) with a 3. 5 mm stereo jack to the telephone’s Audio-Out (3) output, as shown in figure 5.
IP-S400 Audio in / Audio out
The telephone is equipped with an input (2) and an output (3) for audio signals. These ports are provided
for headsets (6).Thejacks are linkedto the corresponding ports for the headset jacks on the bottomof the
telephones.
elmeg IP-S400 at the Ethernet-port
The IP-S400 systemphone can be poweredthrough the Ethernet port as defined inIEEE Std 802.3af-2003
(PoE),withpowerbeingsuppliedviaEthernetfromthehuborswitch.Attheport,»AlternativeA«and»Al
-
Description and installation
8
Figure 5
